CHF 339
Available by special order - Item ordered from our supplier after your purchase
Specially developed by Baader Planetarium for 10Micron frames with high energy demand, this stabilized voltage supply 25 V / 260 W ensures smooth operation without voltage drop for quick check-in or
temperature variations. Why 25 V? The 10Micron control unit accepts 24 - 27 V; setting the output at 25 V guarantees a safety margin when a "conventional" 24 V could fall below 24 V with the load or the load.
in extreme cold. Complies with German safety standards (VDE); ventilated metal housing.
| Parameter | Value |
|---|---|
| Manufacturer reference | Baader #1452070 |
| Mains input | 100 - 240 V AC / 50-60 Hz, 2.5 A max. |
| Output voltage | 25 V DC (ripple < 80 mV p-p) |
| Direct current | 10,5 A |
| Rated power | 260 W |
| Connections | 2 x 4 mm banana plugs (red/black) |
| Weight | ≈ 3.3 kg [oai_citation:4‡osCommerce](https://www.microglobe.co.uk/baaderstabilisedpowersupplyforgm2000andgm3000-p-20875.html?utm_source=chatgpt.com) |
| Dimensions | 240 × 140 × 70 mm (W × D × H) |
| Certifications | CE, RoHS, VDE |
| EAN | 4047825016669 |
CAUTION: to maintain your 10Micron warranty, use only
manufacturer-approved power supplies.
Supplied with EU (Schuko) power cord and user guide. Adapter to
the control box supplied with your mount.
