90° prism-based angled mirror for comfortable viewing with 31.75 mm eyepieces. Ring clamp and 63.5 mm optical path.
CHF 109.55incl. Swiss VAT
Reference TKA00547
Will be ordered for you
Delivery time: 5 to 7 business days
Estimated shipping: Between November 23 and 24, 2026
The Takahashi TKA00547 angled prism deflects the light path by 90°. Placed between the eyepiece holder and the eyepiece, it allows you to maintain a more comfortable viewing position when your telescope is pointed near the zenith.
The outlet accommodates 31.75-mm eyepieces and secures them with a ring clamp. The prism erects the image vertically; the right and left sides remain reversed.
The 31.75 mm eyepiece fits into the instrument’s eyepiece holder. The added optical path length is 63.5 mm: refer to your telescope’s assembly diagram to select the rings and extension tubes needed for focusing. This mirror is not designed for Newtonian telescopes.
The inlet spout does not have a thread for screwing on a filter. The photograph shows the adapter alone, in the version with the shiny metal tip typical of European plugs.
| Features | Value |
|---|---|
| Reference | TKA00547 |
| Type | Angled Prism Deflector |
| Deviation | 90° |
| Input | 31.75 mm insert-type spout |
| Output | 31.75 mm with ring clamp |
| Optical path | 63.5 mm |
| Dimensions | 60 × 43 × 40 mm |
