Pocket Powerbox Advance Gen2 (PPBADV Gen2) from Pegasus Astro
Visit Pocket Powerbox Advance Gen2 (PPBADV Gen2) from Pegasus Astro is a compact power supply and power management solution, ideal for demanding astrophotographers and astronomers.
Concentrated power in a compact format
The blue-anodized aluminum case, measuring just 100 mm x 71 mm x 24 mm and weighing just 250 g, makes the PPBADV Gen2 perfect for nomadic, high-performance astrophotography set-ups.
Advanced power management
- 4 12 V DC outputs : Sockets can be activated/deactivated via dedicated software, for a combined total of 10 A with overvoltage protection.
- Adjustable regulated output : A dedicated socket with adjustable voltage (3V, 5V, 8V, 9V or 12V), ideal for devices such as DSLRs and Raspberry Pi.
- Integrated protection : Integrated voltmeter monitors input voltage for enhanced equipment safety.
Integrated USB3 hub for modern peripherals
- 2 SuperSpeed USB3 ports (5 Gbps).
- 2 High-Speed USB2 ports for optimal accessory connectivity.
Checking heating resistors for astrophotography
- Two PWM outputs compatible with heaters or flatboxes, for precise temperature control.
- Automate heating management with the included environmental sensor.
Stand-alone or connected mode
Visit Pocket Powerbox Advance Gen2 operates in stand-alone mode or can be controlled via a PC with Pegasus Astro software, compatible with ASCOM and INDI.
Integrated environmental sensor for optimum conditions
- Relative humidity : 0 to 100 % with accuracy from ±2 to ±5 %.
- Temperature : -40°C to +80°C with ±0.5°C precision for adjusting optics heating.
Extensive connectivity for easy management
- USB3 Type B port for PC communication.
- RJ12 port to connect external accessories such as focus motors.
- Standard DC socket (2.1 mm) for power supply input.
Practical applications for astrophotographers and astronomers
- Long exposure astrophotography : Power your CCD/CMOS cameras, filter wheels and heaters with optimized energy management.
- Nomadic observation : Compact, self-contained solution for travelling astronomers.
- Centralized management : Consolidate all your cables and connections in a single device to save space.
Box contents
- Pocket Powerbox Advance Gen2.
- External temperature/humidity sensor.
- 4 DC power cables (1 m long).
- USB Type B cable (1.8 m).
- User manual.
Outstanding features of PPBADV Gen2
- Compact, robust design for long-lasting durability.
- Advanced energy management for optimum performance.
- High-performance USB3 hub compatible with modern accessories.
- Automatic heater control based on weather conditions.
Conclusion: a powerhouse for your astronomy sessions
Visit Pocket Powerbox Advance Gen2 simplifies the management of your astrophotography equipment, while offering exceptional reliability and performance for all your night-time observations.
Reference and Configuration
| Brand |
Pegasus Astro |
| Manufacturer reference |
PEG-PPBADV |
| Model / Configuration |
Pocket Powerbox Advance Gen2 |
How do I check for compatibility?
Before setting up your system, compare the exact part number, generation, and connection types of your equipment with the manufacturer’s documentation. An accessory from a different generation is not necessarily interchangeable.
Documentation: Pegasus Astro, manufacturer information. To verify a specific configuration, please provide the reference number PEG-PPBADV to Deep Space Astronomy.
