More products from the brand :Wanderer Astro

Wanderer Astro - Motorized flap panel WandererCover V4-EC IR

Name: Wanderer Astro - Panneau à flats motorisé WandererCover V4-EC IR - Deep space astronomy
Price: 379 CHF
Availability: InStock

Price range: CHF 319 through CHF 779

Diameter (> to mist guard!)

Clear

Livraison contre signature gratuite

Easy, free returns

WandererCover V4-EC IR - Motorized flap panel with infrared remote control

Controllable via ASIAIR / StellaVitacompatible ASCOM and INDIthe WandererCover V4-EC IR is the new generation of motorized flap panel. Ultra-light and robust, it differs from the classic V4-EC model in its direct control via infrared remote control - ideal for field and nomadic setups. No need for USB: a simple cable 12V is enough to manage everything.

Why choose the IR version?

Infrared remote control no need to connect a USB cable if you're not using ASCOM - simplifies setup in the field.
Quick installation a single cable 12V powers and controls the system.
Perfect for ASIAIR simplified management without the need for a computer.
Nomad-friendly fewer cables, fewer points of failure, more fluidity for your nights.

Key features

Built-in micro-encoder real-time feedback, ±0,25° precision, customizable angles.
Reinforced motor +50 % load capacity, cold-resistant (up to -25 °C), more than 3,000 cycles tested.
Anti-mist heating panel : keeps the flat dry all night and evaporates dew in the morning, can be controlled in NINA ("Device Actions and Commands" plugin).
Perfect flats Enhanced PWM controller (×2), 255 levels brightness, no stripes as soon as 0,1 snarrowband flats (3 nm) in ~1 s.
Exclusive cable management anti-tear solution, soft pads scratch-resistant, including universal clamps.
Extended compatibility : ASCOM, INDI, ASIAIR Plus, StellaVita (via DC output).

Warning: not compatible with the ASIAIR integrated in ZWO AIR series cameras.

Quick selection guide (luminous diameter)

Golden rule : always choose a model with a luminous diameter ≥ outer diameter of the mist shield.

Example: bezel 100 mm with mist guard Ø 120 mm → choose 125IR.

Model	Luminous diameter	Typical* compatibility
WMFP4-80IR	≈ 80 mm	Small glasses 60-70 mm
WMFP4-100IR	≈ 100 mm	Bezels 72-85 mm
WMFP4-125IR	≈ 125 mm	Bezels 90-102 mm
WMFP4-150IR	≈ 150 mm	Bezels 107-120 mm / small Newton
WMFP4-190IR	≈ 190 mm	Newton 150-200 mm / SCT 6-8
WMFP4-225IR	≈ 225 mm	Newton 200-250 mm / SCT 9.25"
WMFP4-240IR	≈ 240 mm	Newton 250 mm / SCT 10

*General information: always measure the outside diameter of the mist guard.

Technical specifications

Control	Infrared remote control + ASCOM + INDI + ASIAIR / StellaVita (via DC)
Encoder	Angle feedback, precision ±0.25°.
Engine	+50 % load, low temperature, > 3,000 cycles
Cold resistance	-25 °C
Anti-water heating	Integrated, control via NINA plugin
Flats	255 levels, no-banding ≥ 0.1 s, narrowband in ~1 s
Power supply	DC 12V (1 cable is sufficient for IR mode)
Accessories included	Clamps, protection pads

Included in the box

1× WandererCover V4-EC IR (size according to selection)
Infrared remote control
Clamps / ties
Fog shield protection pads
User manual (downloadable)

FAQ

What's the difference with the classic V4-EC?
The IR model includes a infrared remote controlThis means it can be used without USB, and only with a 12V power supply. Easier for nomad setups and ASIAIR.

Do I need a PC to control it?
No, with the remote control you can open/close directly. For automation (NINA sequences, etc.), USB/ASCOM is still possible.

Is it compatible with ASIAIR?
Yes, with the latest firmware and DC output. Please note: not compatible with the ASIAIR integrated in some ZWO cameras.

Is the heating system automatic?
No, but it is controllable in NINA via plugin. It can be activated continuously to prevent humidity.

Can I use the remote control and ASCOM in parallel?
Yes, IR is an additional control mode that simplifies life on the move.
